Product Details
Features
The UPVC Welding Machine is used to join uPVC profile corners by applying heat and pressure, forming strong and durable 90-degree joints. It ensures precise alignment and consistent weld quality, essential for the strength and airtightness of windows and doors. Available in single head welding machine, double head welding machine, and four head welding machine, some models also support seamless welding for a cleaner finish. The double head upvc welding machine improves efficiency, reduces manual errors, and is a key equipment in any uPVC window and door production line.
- Application: Double head upvc welding machine is suitable for welding uPVC/PVC/vinyl profiles. A key machine for making uPVC windows and doors.
- Versatile Welding: Two heads controlled by a PC system, capable of welding various shapes including┏,┏┓,┏┳┓,┏┳┳┳, ┳, ┳┳, ┳┳┳, ╋ and etc.
- Precise Pneumatic Drive: Pneumatic transmission with CM oil-free bearings and linear ball bearings for high precision, easy operation, and low maintenance.
- Flexible Head Operation: Each head can operate independently or combine for coordinated welding, offering flexibility in the welding process.
- Various Welding Angles: One head can weld at any angle, ideal for welding curved or custom-shaped windows.
- Options: Single head welding machine, three head welding machine, four head welding machine, seamless welding machines.
Specifications
| Model | HJ02-3500. 2/2A |
| Power input | Base on request |
| Motor power | 2.5KW |
| Welding height&width | H=20-120mm; W=0-120mm |
| Air pressure | 0.5-0.8Mpa |
| Machine size | 4400*1100*1700mm |
| Weight | 900KG |
Video
https://youtu.be/kEA6mlWpdSQ?si=PuWXF1rsa77jiu2m
UPVC Window Production Line
- Double head cutting machine: cutting profiles
- Lock hole copy router: milling holes
- Water slot milling machine: milling water slot (Drainage hole)
- End milling machine or V notch cutting machine: mullion profile processing
- Screw fastening machine: connect steel lining with the PVC profile to improve profile strength
- Welding machine: forming frame and sash
- Cleaning machine: cleaning the overlap formed during welding
- Bead cutting saw: cutting the bead profile
- Bending machine: bending arc if needed
